| MAIN TECHNICAL PARAMETER/ 50HZ 3PHASES, 1500RPM | |||||||||||
| Genset Model | Prime Power | Standby Power | Engine | Fuel Consumption(L/hr) | Silent Type Generator | ||||||
| KVA | KW | KVA | KW | Model | NO.Cylinder | Governor | 100% | Dimention L×W×H(mm) |
Weight (KG) |
Sound level at 7m(dBA) | |
| GP22DC | 20 | 16 | 22 | 17.6 | 4B3.9-G1 | 4.L | M | 4.5 | 2200×1000×1335 | 1050 | 68 |
| GP27.5DC | 25 | 20 | 27.5 | 22 | 4B3.9-G1 | 4.L | M | 5.5 | 2200×1000×1335 | 1080 | 68 |
| GP33DC | 30 | 24 | 33 | 26.4 | 4BT3.9-G1 | 4.L | M | 6.7 | 2350×1000×1335 | 1120 | 70 |
| GP41.25DC | 37.5 | 30 | 41.25 | 33 | 4BT3.9-G1 | 4.L | M | 8.3 | 2350×1000×1335 | 1160 | 70 |
| GP44DC | 40 | 32 | 44 | 35.2 | 4BT3.9-G1 | 4.L | M | 8.9 | 2350×1000×1335 | 1160 | 70 |
| GP55DC | 50 | 40 | 55 | 44 | 4BTA3.9-G2 | 4.L | E | 11 | 2650×1020×1480 | 1350 | 70 |
| GP66DC | 60 | 48 | 66 | 52.8 | 4BTA3.9-G2 | 4.L | E | 13 | 2650×1020×1480 | 1400 | 70 |
| GP66DC | 60 | 48 | 66 | 52.8 | 4BTA3.9-G11 | 4.L | E | 13 | 2650×1020×1480 | 1400 | 70 |
| GP68.75DC | 62.5 | 50 | 68.75 | 55 | 4BTA3.9-G2 | 4.L | E | 13.8 | 2650×1020×1480 | 1520 | 70 |
| GP80DC | 72.5 | 58 | 80 | 64 | 4BTA3.9-G11 | 4.L | E | 16 | 2650×1020×1480 | 1520 | 70 |
| GP88DC | 80 | 64 | 88 | 70.4 | 6BT5.9-G2 | 6.L | E | 17 | 2970×1120×1580 | 1560 | 72 |
| GP110DC | 100 | 80 | 110 | 88 | 6BT5.9-G2 | 6.L | E | 21.2 | 2970×1120×1580 | 1750 | 72 |
| GP123.75DC | 112.5 | 90 | 123.75 | 99 | 6BTA5.9-G2 | 6.L | E | 23.8 | 2970×1120×1580 | 1800 | 72 |
| GP137.5DC | 125 | 100 | 137.5 | 110 | 6BTAA5.9-G2 | 6.L | E | 26.5 | 3200×1120×1580 | 1900 | 75 |
| GP165DC | 150 | 120 | 165 | 132 | 6BTAA5.9-G12 | 6.L | E | 31.8 | 3200×1120×1580 | 1950 | 75 |
| GP165DC | 150 | 120 | 165 | 132 | 6CTA8.3-G2 | 6.L | E | 31.8 | 3400×1280×1785 | 2350 | 75 |
| GP206.25DC | 187.5 | 150 | 206.25 | 165 | 6CTA8.3-G2 | 6.L | E | 39.7 | 3400×1280×1785 | 2400 | 75 |
| GP220DC | 200 | 160 | 220 | 176 | 6CTAA8.3-G2 | 6.L | E | 42.4 | 3600×1280×1860 | 2450 | 75 |
| GP247.5DC | 225 | 180 | 247.5 | 198 | 6LTAA8.9-G2 | 6.L | E | 47.7 | 3600×1280×1860 | 2800 | 78 |
| GP275DC | 250 | 200 | 275 | 220 | 6LTAA8.9-G2 | 6.L | E | 53 | 3600×1280×1860 | 2800 | 78 |
| GP275DC | 250 | 200 | 275 | 220 | 6LTAA8.9-G3 | 6.L | E | 53 | 3600×1280×1860 | 2800 | 78 |
| GP412.5DC | 375 | 300 | 412.5 | 330 | 6ZTAA13-G3 | 6.L | E | 76.5 | 4200×1400×2000 | 4000 | 82 |
| GP440DC | 400 | 320 | 440 | 352 | 6ZTAA13-G2 | 6.L | E | 89.1 | 4200×1400×2000 | 4000 | 82 |
| GP480DC | 437.5 | 350 | 480 | 384 | 6ZTAA13-G2 | 6.L | E | 89.1 | 4300×1400×2000 | 4400 | 82 |
| GP495DC | 450 | 360 | 495 | 396 | 6ZTAA13-G4 | 6.L | E | 91.4 | 4300×1400×2000 | 4400 | 83 |
| GP495DC | 450 | 360 | 495 | 396 | QSZ13-G2 | 6.L | ECU | 88.8 | 4300×1400×2000 | 4400 | 83 |
| GP550DC | 500 | 400 | 550 | 440 | QSZ13-G3 | 6.L | ECU | 101 | 4300×1400×2000 | 4400 | 83 |
| Genset Model | Prime Power | Standby Power | Engine | Fuel Consumption(L/hr) | Silent Type Generator | ||||||
| KVA | KW | KVA | KW | Model | NO.Cylinder | Governor | 100% | Dimention L×W×H(mm) |
Weight (KG) |
Sound level at 7m(dBA) | |
| GP302.5CC | 275 | 220 | 302.5 | 242 | NTA855-G1A | 6.L | E | 57 | 4200×1400×2000 | 3400 | 80 |
| GP330CC | 300 | 240 | 330 | 264 | MTAA11-G3 | 6.L | E | 62 | 4500×1600×1800 | 3800 | 80 |
| GP343.75CC | 312.5 | 250 | 343.75 | 275 | MTAA11-G3 | 6.L | E | 64.7 | 4500×1600×1800 | 3900 | 80 |
| GP343.75CC | 312.5 | 250 | 343.75 | 275 | NTA855-G1B | 6.L | E | 64.7 | 4200×1400×2000 | 3800 | 80 |
| GP343.75CC | 312.5 | 250 | 343.75 | 275 | NTA855-G2 | 6.L | E | 64.7 | 4200×1400×2000 | 3800 | 80 |
| GP385CC | 350 | 280 | 385 | 308 | NTA855-G2A | 6.L | E | 72.5 | 4200×1400×2000 | 3900 | 80 |
| GP385CC | 350 | 280 | 385 | 308 | NTA855-G4 | 6.L | E | 72.5 | 4200×1400×2000 | 3900 | 80 |
| GP385CC | 350 | 280 | 385 | 308 | QSM11-G2 | 6.L | ECU | 72.5 | 4200×1400×2000 | 3900 | 80 |
| GP412.5CC | 375 | 300 | 412.5 | 330 | NTAA855-G7 | 6.L | E | 77.7 | 4300×1600×2000 | 4000 | 82 |
| GP440CC | 400 | 320 | 440 | 352 | NTAA855-G7A | 6.L | E | 82.9 | 4300×1600×1800 | 4000 | 82 |
| GP495CC | 450 | 360 | 495 | 396 | KTA19-G3 | 6.L | E | 93.3 | 4700×1650×2230 | 5200 | 83 |
| GP550CC | 500 | 400 | 550 | 440 | KTA19-G3A | 6.L | E | 93.3 | 4700×1650×2230 | 5200 | 83 |
| GP550CC | 500 | 400 | 550 | 440 | KTA19-G4 | 6.L | E | 103.6 | 4700×1650×2230 | 5200 | 83 |
| GP618.75CC | 562.5 | 450 | 618.75 | 495 | KTAA19-G5 | 6.L | E | 116.5 | 5000×1800×2450 | 5500 | 83 |
| GP660CC | 600 | 480 | 660 | 528 | KTAA19-G6 | 6.L | E | 124.3 | 5000×1800×2450 | 5500 | 83 |
| GP660CC | 600 | 480 | 660 | 528 | KTA19-G8 | 6.L | E | 124.3 | 5000×1800×2450 | 5500 | 83 |
| GP687.5CC | 625 | 500 | 687.5 | 550 | KTAA19-G6A | 6.L | E | 129.5 | 5000×1800×2450 | 5500 | 83 |
| GP687.5CC | 625 | 500 | 687.5 | 550 | KTAA19-G7 | 6.L | E | 129.5 | 5000×1800×2450 | 5500 | 83 |
| GP712.5CC | 650 | 520 | 712.5 | 570 | QSKTAA19G4 | 6.L | ECU | 145 | 5200×1800×2450 | 6300 | 83 |
| GP825CC | 750 | 600 | 825 | 660 | KTA38-G2 | 12.V | E | 155.4 | 6050×2435×2589(20P) | 9500 | 85 |
| GP880CC | 800 | 640 | 880 | 704 | KTA38-G2B | 12.V | E | 165.8 | 6050×2435×2585(20P) | 9500 | 85 |
| GP990CC | 900 | 720 | 990 | 792 | KTA38-G2A | 12.V | E | 186.5 | 6050×2435×2585(20P) | 9700 | 85 |
| GP1100CC | 1000 | 800 | 1100 | 880 | KTA38-G5 | 12.V | E | 207 | 6050×2435×2585(20P) | 9900 | 85 |
| GP1237.5CC | 1125 | 900 | 1237.5 | 990 | KTA38-G9 | 12.V | E | 233 | 6050×2435×2585(20P) | 11300 | 85 |
| GP1375CC | 1250 | 1000 | 1375 | 1100 | KTA50-G3 | 16.V | E | 259 | 12192×2435×2896(40HP) | 11900 | 86 |
| GP1512.5CC | 1375 | 1100 | 1512.5 | 1210 | KTA50-G8 | 16.V | E | 285 | 12192×2435×2896(40HP) | 13000 | 86 |
| GP1650CC | 1500 | 1200 | 1650 | 1320 | KTA50-GS8 | 16.V | E | 311 | 12192×2435×2896(40HP) | 13000 | 86 |
Delivery Time: 30 days after deposite
Package: nude packing or plywooden case
Description:
1. Power Range: 20-2500kw
2. Engine: DCEC Cummins, CCEC Cummins, USA Cummins
3. Alternator: Genuine Stamford, Marathon, Meccalte, etc
4. Controller: Deepsea or Smartgen with or without AMF. Options: remote controller, synchronizing,
5. ATS is optional
6. Type: Open type, Soundproof type, Trailer type, Container type, etc
7. Color: Can be customized
Applications:
1. Industrial area: real estate, hospital, hotel, bank,construction, factory, oil field, airport, mining, railway
2. Home use: personal use for house, camping, party, etc
3. Telecom, Mobile tower, etc
4. Island, Desert or any place without electricity
5. As for emergency equipment special for natural disasters, such as typhoon, earthquake, heavy snow,
6. Standby power or main power, indoor or outdoor using.
Competitive Advantage:
1. Full power range.
2. All genuine engines and alternators.
3. The components we use are in high quality.
4. Fast delivery. Big quantity of Engines in stock.
5. The generator set is mounted on a heavy duty fabricated steel skid type base– frame with anti vibration mounting pads.
6. Use high standard of sponge to make soundproof.
7. The canopy design is user friendly, and easy for maintenance.
8. Pre and after sales service is provided.
9. Fast response for the inquires, service, etc.
There are many international brand generator controller for our cusomer 's choice,such as Smartgen, Deep sea, Compny, Harson and so on.
ATS: Upon detection of a mains(utility) failure the module automatically starts the generator set, once the mails (utility) power has been restored it instructs the generator set to stop.
Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card
Optional supply scope:
1.ATS 2. SynchronizationSystem 3. External daily fuel tank 4. Silent Canopy 5. Trailer 6. Auto Fuel Pump 7. Fuel and Water Separator 8. Lub Oil Heater 9. Coolant Heater 10. Fuel Drain Pump
Advantages:
. A strong R&D team with rigorous selection and trainning
. Several years experiences in desinging and manufacturing diesel generator sets.
. Good reputation for reliable quality and reasonable price
. Advanced production line with skilled workers
Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours
If have any questions, please contact us. Your inquiry would be appreciated.
| FAQ |
Q1: What is your warranty period?
A1: Our warranty period is 1 year or 1000 running hous, whichever comes first(Excep the damageable spare parts of genset caused by incorrect man-made operation).
Q2: Does your generator have global warranty?
A2: Yes. Global warranty service is available depending on the engines and alternators you choose. Please contact us for more details.
Q3: What is your payment terms?
A3: T/T 30% advance payment, the balance 70% shall be paid before shipment.
L/C Irrevocable L/C at sight.
Q4: What is your delivery time?
A4: Our standard delivery time is 20 to 30 days. If you have urgent demand, the delivery will be shorter depending on the requirements. If you have special requirements, the delivery will be longer.
Q5: Can the generators be customized?
A5: Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, inudstrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.
Q6: Can you use our logo?
A6: Yes. For mass orders, we can use customer's logo instead of ours.
