Prime 200kw Lower Noise House Power Generator FPT Engine Three Phase

1
MOQ
16500-18500
Price
Prime 200kw Lower Noise House Power Generator FPT Engine Three Phase
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Prime 200kw Lower Noise Power Generator
Certificate: CE/ISO9001
Phase Number: 3
Power Factor: 0.8
Engine Model: FPT FPT/CURSOR87TE3
Genset Structure: SILENT
Insulation Class: H
Protection Class: IP23
Construction Type: SAE Disc-coupling
Displacement: 8.7L
High Light:

water cooled diesel generator

,

electric generating set

Basic Infomation
Place of Origin: China
Brand Name: GPRO
Certification: CE/ISO9001
Model Number: GP275FPS
Payment & Shipping Terms
Packaging Details: Packed in Foam and Ply wooden box.
Delivery Time: 1 month
Product Description

Prime 200kw Lower Noise House Power Generator FPT Engine Three Phase



Technical specification
Genset Model GP275FPS
Prime Power 200KW/250KVA
Standby Power 220KW/275KVA
Phase Number 3
Power Factor 0.8
Rated Voltage 230/400V
Frequency 50 HZ
Rated Current 360.8A
Genset Structure SILENT
Dimension 3800×1380×1980mm
Net Weight 3800KG
Noise level 80 dba @ 7 meters
Engine Model FPT FPT/CURSOR87TE3
Engine Features 6-cylinder,4 stroke,, turboafter cooler
Bore * Stroke 117mm × 135mm
Displacement 8.7L
12-hour Power(kw) 229KW/1500
Fuel Consumption L/H 58L/H
Compression Ratio 15.9:1
Governor type Common Rail
Alternator Model MECC ALTE/ECO38-1LN/4
Excitation Mode brushless self-excited
Insulation Class H
Protection Class IP23
Construction Type SAE Disc-coupling
Controler panel
Smartgen 6120 intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.automatic switching control functions (AMF), especially suitable for the automation system composed by Mains and Generator



Prime 200kw Lower Noise House Power Generator FPT Engine Three Phase 0



There are many international brand generator controller for our cusomer 's choice,such as Smartgen, Deep sea, Compny, Harson and so on.



ATS: Upon detection of a mains(utility) failure the module automatically starts the generator set, once the mails (utility) power has been restored it instructs the generator set to stop.



Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card



Optional supply scope:
1.ATS

2.SynchronizationSystem

3.External daily fuel tank

4.Silent Canopy

5.Trailer

6.Auto Fuel Pump

7.Fuel and Water Separator

8.Lub Oil Heater

9.Coolant Heater

10.Fuel Drain Pump

Advantages:

. We are a powerful and unity sales team:

. we are not just sales, but also professional engineers here to give you fast response of Technical support and power solutions.

90% of our sales team members are with more than 5 years of experience in the generator field.

. We have professional electrical & mechanical engineers, standby you, to solve the pre/after-sales service.

. We have strict Inspection dept. to make sure each genset is carefully test before leaving factory.

. With the experience and knowledge of Gensets, we are enthusiastic and patient, and can communicate with you easily and efficiently.



Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours



If have any questions, please contact us. Your inquiry would be appreciated.

Prime 200kw Lower Noise House Power Generator FPT Engine Three Phase 1
