500KVA 400KW Diesel Power Perkins Diesel Water Cooled Generator With Stamford Alternator

1 SET
MOQ
Negotiation
Price
500KVA 400KW Diesel Power Perkins Diesel Water Cooled Generator With Stamford Alternator
Features Gallery Product Description Request A Quote
Features
Specifications
Output Power: 500kva/400kw
Frequency: 50/60HZ
Voltage: 220v - 690v Optional
Alternator: Stamford, Meccalte, Leroy Somer, Marathon, Wattek For Optional
Controller: Deepsea, Smartgen, Harsen For Optional
MCCB: ABB Or Delixi
Cooling System: Water Cooled
Genset Type: Open Type, Silent Type, Container Type, Trailer Type For Optional
ATS: Optional
Engine Brand: Uk Perkins
High Light:

open type genset

,

water cooled generator

Basic Infomation
Place of Origin: Jiangsu of China
Brand Name: GPRO
Certification: ISO,CE Certification
Model Number: GP550P
Payment & Shipping Terms
Packaging Details: Plywood or Plastic packing
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 300 Set / Month
Product Description

500KVA 400KW Diesel Power Perkins Diesel Water Cooled Generator With Stamford Alternator



Technical specification
Genset Model GP550P
Prime Power 400KW/500KVA
Standby Power 440KW/550KVA
Phase Number 3
Power Factor 0.8
Rated Voltage 230/400V
Frequency 50 HZ
Rated Current 722A
Genset Structure Open type
Dimension 3500×1120×2050mm
Net Weight 3700KG
Noise level 102dB at 7 meters
Fuel Tank Capacity 750L
Engine Model 2506C-E15TAG2
Engine Features 6-cylinder,4 stroke,water cooled ,Turbo
Bore * Stroke 137mm × 171mm
Displacement 15.2L
12-hour Power(kw) 435KW/1500
Fuel Consumption L/H 101.2L/H
Compression Ratio 16:01
Governor type ECU
Alternator Model STAMFORD /HCI544D
Excitation Mode brushless self-excited
Insulation Class H
Protection Class IP23
Construction Type SAE Disc-coupling
Controler panel
Deepsea 7320 intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.automatic switching control functions (AMF), especially suitable for the automation system composed by Mains and Generator



500KVA 400KW Diesel Power Perkins Diesel Water Cooled Generator With Stamford Alternator 0

There are many international brand generator controller for our cusomer 's choice,such as Smartgen, Deep sea, Compny, Harson and so on.



ATS: Upon detection of a mains(utility) failure the module automatically starts the generator set, once the mails (utility) power has been restored it instructs the generator set to stop.



Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card



Optional supply scope:
1.ATS

2.SynchronizationSystem

3.External daily fuel tank

4.Silent Canopy

5.Trailer

6.Auto Fuel Pump

7.Fuel and Water Separator

8.Lub Oil Heater

9.Coolant Heater

10.Fuel Drain Pump



Advantages:

. We are a powerful and unity sales team:

. we are not just sales, but also professional engineers here to give you fast response of Technical support and power solutions.

90% of our sales team members are with more than 5 years of experience in the generator field.

. We have professional electrical & mechanical engineers, standby you, to solve the pre/after-sales service.

. We have strict Inspection dept. to make sure each genset is carefully test before leaving factory.

. With the experience and knowledge of Gensets, we are enthusiastic and patient, and can communicate with you easily and efficiently.



Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours



If have any questions, please contact us. Your inquiry would be appreciated.
