Contact Person : Karen Zou
Phone Number : +86-13720828359
WhatsApp : +008613720828359

Electric Open Type Diesel Silent Generator Stamford Meccalte Leroy Somer

Place of Origin Jiangsu of China
Brand Name Power Friend
Certification ISO,CE Certification
Model Number PF-F62
Minimum Order Quantity 1 SET
Price Negotiation
Packaging Details Plywood or Plastic packing
Delivery Time 15 - 20 working day
Payment Terms L/C, T/T
Supply Ability 300 Set / Month
Product Details
Output Power 50KW Frequency 50/60HZ
Voltage 220v - 690v Optional Engine Cummins, Perkins, Deutz, Iveco, Chinese Brand For Optional
Alternator Stamford, Meccalte, Leroy Somer, Marathon, Wattek For Optional Controller Deepsea, Smartgen, Harsen For Optional
MCCB ABB Or Delixi Cooling System Water Cooled
Genset Type Open Type, Silent Type, Container Type, Trailer Type For Optional ATS Optional
High Light

industrial diesel generators

,

diesel genset

Leave a Message
Product Description

 Electric Genset Open Type Diesel Power Generator Set Low Price



Genset Specification
Model   PF-F62
Prime Power KW 50
  KVA 62
Standby Power KW 55
  KVA 68
Power Factor   0.8
Frequency Hz 50
Rate Voltage V 380/220
Fuel Tank Capacity L (Base frame) 100
Fuel Consumption L/Hour 12.2
Sound @7 meter                       Db 68
Open Type Product size L×W×H 1850*700*1400
Open Type Weight net kg 1110
Canopy type product size L×W×H 2300*1060*1300
Canopy Type Weight net kg 1280

Engine Specification
Model FAW Xichai 4DF1-07D
Structure   4 cylinders
Fuel type   Diesel
Governor   Electronic
Coolling   Water

Alternator Specification
Model Wattek 224E
Excitation mode   Self-excitation
Insulation class   H
Protection class   IP23
TIF   <50
THF   <2%
Air flow m³/s 0.8



Electric Open Type  Diesel Silent Generator Stamford Meccalte Leroy Somer 0



Electric Open Type  Diesel Silent Generator Stamford Meccalte Leroy Somer 1


Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card

Optional supply scope:
1.ATS 2. SynchronizationSystem 3. External daily fuel tank 4. Silent Canopy 5. Trailer 6. Auto Fuel Pump 7. Fuel and Water Separator 8. Lub Oil Heater 9. Coolant Heater 10. Fuel Drain Pump

Advantages:
. A strong R&D team with rigorous selection and trainning
. Several years experiences in desinging and manufacturing diesel generator sets.
. Good reputation for reliable quality and reasonable price
. Advanced production line with skilled workers

Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours


If have any questions, please contact us. Your inquiry would be appreciated.
