Original Italy diesel engine brand.
Euro standard production , strict quality control.
Some model engines approval EPA TIER 4 and Euro stage III emission requirement.
MAIN TECHNICAL PARAMETER/ 50HZ 3PHASES, 1500RPM:
| 1.SPECIFICATIONS OF GEN-SET |
| Set Model |
GP440FPS |
| Prime at 50HZ, 40℃ ambient |
320kW 400KVA |
| Standby at 50HZ, 40℃ ambient |
352kW 440KVA |
| Rated Gen-set output |
220/380V 50Hz |
| Rated Relative humidity |
≤ 60 % |
| Dimension (L×W×H) |
4800x1400x2230mm |
| Weight |
5000kg |
| Fuel consumption 100% prime load |
85.8L/h |
| Noise Level at 7m |
75dB |
| 2.SPECIFICATIONS OF ENGINE |
| Engine Brand |
FPT |
| Engine Model |
C13 |
| Governor/Class |
ECU |
| Electronic engine control unit |
BOSCH EDC7 UC31 |
| Cylinder NO. |
6 |
| Engine build |
Line |
| Fuel spray pattern |
PT direct injection |
| start-up method |
24V, electric |
| Valves per cylinder |
4 |
| Cooling system |
liquid (water + 50% Paraflu11) |
| Bore and stroke |
135 x 150 mm |
| Induction System |
turbo aftercooler air/air |
| Displacement |
12.88L |
| Battery capacity |
100A/hr |
| Cold starting: without air preheating |
-10 ℃ |
| Lube oil consumption |
<0.1% of fuel consumption |
| Coolant capacity - radiator and engine (50℃) |
68L |
| Fuel type |
#0 Diesel (Natural temperature) |
| 3.SPECIFICATIONS OF ALTENATOR |
| Alternator Brand |
China Stamford |
| Alternator Type |
A.C. Synchronous |
| Rated Voltage |
220/380V |
| Rated Frequency |
50HZ/60HZ |
| Rated speed |
1500 RPM/1800RPM |
| Voltage regulation mode |
Auto |
| Alternator voltage regulation |
±0.5% |
| Exciting mode |
Brushless self exciting |
| Power factor |
0.8 (lagging) |
| Phase & wires |
3 phase 12 wires |
| Protection class |
IP23 |
| Single load step to NFPA110 |
100% |
| Max. Ambient Temperature |
40℃ |
| Min. Ambient Temperature |
- 20℃ |
| Max. altitude |
1000m |
| Weight |
1160kg |
There are many international brand generator controller for our cusomer 's choice,such as Smartgen, Deep sea, Compny, Harson and so on.
ATS: Upon detection of a mains(utility) failure the module automatically starts the generator set, once the mails (utility) power has been restored it instructs the generator set to stop.
Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card
Optional supply scope:
1.ATS 2. SynchronizationSystem 3. External daily fuel tank 4. Silent Canopy 5. Trailer 6. Auto Fuel Pump 7. Fuel and Water Separator 8. Lub Oil Heater 9. Coolant Heater 10. Fuel Drain Pump
Advantages:
. We are a powerful and unity sales team:
. we are not just sales, but also professional engineers here to give you fast response of Technical support and power solutions.
90% of our sales team members are with more than 5 years of experience in the generator field.
. We have professional electrical & mechanical engineers, standby you, to solve the pre/after-sales service.
. We have strict Inspection dept. to make sure each genset is carefully test before leaving factory.
. With the experience and knowledge of Gensets, we are enthusiastic and patient, and can communicate with you easily and efficiently.
Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours
