Water pump description:
1.Lower consumption, lower noise, lower pollution. Higher efficiency and environmental friendly
2.Strict testing system, stable voltage and frequency
3.Secured ground terminal
4.Stronger automatic startup system, staring within only 1-5s
5.Smart in size, delicate in style, longer service life
6.very diversified and customerized choices
| Mode | PD50D(E) | PD80D(E) | PD100D(E) |
| Suction, discharge port diameter (mm/in) | 50/2 '' | 80/3'' | 100/4'' |
| Discharge capacity (m3/h) | 22 | 30 | 40 |
| Max head (m) | 15 | 13 | 16 |
| Max suction (m) | 8 | 8 | 8 |
| Engine speed (rpm) | 3600 | 3600 | 3600 |
| Priming time (s/4m) | 80 | 120 | 180 |
| overall dimension (LxWxH) | 520x420x580 | 590x470x600 | 680X500X660 |
| Engine Model | 170F(E) | 178F(E) | 186FA(E) |
| Structure type | Single cylinder, in lined, 4-stroke, air-cooled, direct-injected |
Single cylinder, in lined, 4-stroke, air-cooled, direct-injected |
Single cylinder, in lined, 4-stroke, air-cooled, direct-injected |
| Starting System | Recoil or Electric | Recoil or Electric | Recoil or Electric |
| Rated power kw | 2.8 | 4 | 6.3 |
| Engine Horse Power | 3.808 | 5.44 | 8.568 |
| Displacement ML | 211 | 296 | 406 |
| Net weight kg | 35 | 52 | 69 |
| Fuel tank capacity L | 2.5 | 3.5 | 5.5 |
| Fuel consumption ( g/kw.h) | 288 | 285 | 281 |
JIANGSU UNITED POWER FRIEND TECHNOLOGY CO., LTD is focus on power generator products and service in China.
Portable Series: 2-12kva, air cooled, 1 or 2 Cylinders, 3000rpm/ 3600rpm
Water Cooled Series: 6-3000kva, water cooled, 3-16 Cylinders, 1500rpm/ 1800rpm
