22KW - 112KW Standby Power Diesel Lovol Generators Set Open type

1 SET
MOQ
Negotiation
Price
22KW - 112KW Standby Power Diesel Lovol Generators Set Open type
Features Gallery Product Description Request A Quote
Features
Specifications
Output Power: 22kw - 112kw
Frequency: 50/60HZ
Voltage: 220v - 690v Optional
Engine: LOVOL
Alternator: Stamford, Meccalte, Leroy Somer, Marathon, Wattek For Optional
Controller: Deepsea, Smartgen, Harsen For Optional
MCCB: ABB Or Delixi
Cooling System: Water Cooled
Genset Type: Open Type, Silent Type, Container Type, Trailer Type For Optional
ATS: Optional
High Light:

high power generator

,

diesel powered generator

Basic Infomation
Place of Origin: Jiangsu of China
Brand Name: GPRO
Certification: ISO,CE Certification
Model Number: PF-L27
Payment & Shipping Terms
Packaging Details: Plywood or Plastic packing
Delivery Time: 15 - 20 working day
Payment Terms: L/C, T/T
Supply Ability: 300 Set / Month
Product Description

22KW - 112KW Standby Power Diesel Lovol Generators Set Open type



22KW - 112KW Standby Power Diesel Lovol Generators Set Open type 0

ALTERNATOR





Rated power (Kw)

22KW-112KW

Voltage (V)

400/230

Current (A)

36.1-195

Frequency (Hz)

50/60

Power factor  cosφ

0.8(lagging)

Excitation mode

Brushless self-excitation

Phase/Connection

3-phase 4-wire  Y type connection

Voltage regulation rated

≤±1%

Voltage Regulation

Automatic

Insulation grade

H

ENGINE

continuous runnung time(H)

≥8

Intaking method

Turbocharged/Tubocharged and air after cooled/

Naturally Aspirated

Bore x stroke  (mm)

3-100×127/4-100×127/6-100*127

Displacement  (L)

3.9/3.99/5.99

Compression ratio

17.5:1/16.5:1

Rated power (Kw)

12KW-220KW

Lube oil capacity (L)

7.48-19

Fuel consumption rate(g/kW.h)

≤210/≤205/≤242

Starting system

24V Electric starter



(1) High Power Density

     More power than competitive models at close displacement, The power of 3-cylindder can reach 4-cylinder level of competitor.

(2) Lower Fuel consumption

   Adopted European patent quadram combusition chamber which can reduced duel consumption, enission and noise, meanwhile Diesel engine with in-line pump for gensets raises engine power .

(3) Good performance of Cold Start

   Started normally at -10°C without preheater, started smoothly at -25°C through flame preheating cold start device, meanwhile -40°C start solution is available.

(4) Stability & Reliability

  Stable and reliable engine performance, good market feedback.



22KW - 112KW Standby Power Diesel Lovol Generators Set Open type 1





 22KW - 112KW Standby Power Diesel Lovol Generators Set Open type 2


Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card

Optional supply scope:
1.ATS 2. SynchronizationSystem 3. External daily fuel tank 4. Silent Canopy 5. Trailer 6. Auto Fuel Pump 7. Fuel and Water Separator 8. Lub Oil Heater 9. Coolant Heater 10. Fuel Drain Pump

Advantages:
. A strong R&D team with rigorous selection and trainning
. Several years experiences in desinging and manufacturing diesel generator sets.
. Good reputation for reliable quality and reasonable price
. Advanced production line with skilled workers

Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours
