Sea water cooling Cummins Marine Diesel Generator rated 120kw electric power genset
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power(Prime/Standby) | 120kw 150kva | Frequency | 50/60hz |
|---|---|---|---|
| Current | Depending On Power | Voltage | 220v-440v |
| Engine | Cummins | Alternator | Stamford/ Marathon |
| Controller | Deepsea/Smartgen | MCCB | ABB/Delixi |
| Warranty | One Year Or 1000hrs | Color | Customized |
| Cooling Method | Sea Water Cooled | ||
| High Light | boat diesel generator,marine diesel genset |
||
Product Description
Sea water cooling Cummins marine diesel generators, Marathon alternators, rated 120kw electric power genset
Genuie Cummins engine, with Marathon alternators or Stamford.
Cooling method: by heat exchanger and sea water pump. Without radiator.
|
Model |
6CTA8.3-GM |
|
Type |
4-storke ,in-line type,turbocharged |
|
No. of cylinder |
6 |
|
Bore |
114mm |
|
Stroke |
135mm |
|
Rated output |
175KW |
|
Rated speed |
1800 r/min |
|
Starting measure |
electric starter motor |
|
Speed control |
Electric governor |
|
Direction of rotation |
anticlockwise(see from flywheel) |
|
cooling type |
Sea water and fresh water |
|
Fuel oil consumption(g/kWh) |
212 |
|
Fuel oil |
US ASTM No. 2 diesel oil China Fuel Type 0 - GB 252-87 ( grade 1 & special grade ) as equivalent China Fuel Type -10 - GB 252-87 ( grade 1 & special grade ) as equivalent |
|
Lub.oil |
SAE 15W40 grade CE or CF4 |
|
Over load capacity |
10% overload capactity for 1 hour within 12operating hour. |
|
Manufactory |
DCEC |
|
Genset Model |
Prime Power/kw |
Engine Model |
Alternator Model |
Controller |
|
BC30GF |
30 |
4BTA3.9 |
GM-H-30-4 |
MFKC200A |
|
BC35GF |
35 |
4BTA3.9 |
MP-H-35-4 |
MFKC200A |
|
BC40GF |
40 |
4BTA3.9 |
MP-H-40-4 |
MFKC200A |
|
BC50GF |
50 |
4BTA3.9 |
MP-H-50-4 |
MFKC200A |
|
BC60GF |
60 |
6BT5.9 |
MP-H-60-4 |
MFKC200A |
|
BC65GF |
65 |
6BT5.9 |
MP-H-65-4 |
MFKC200A |
|
BC80GF |
80 |
6BT5.9 |
MP-H-80-4 |
MFKC200A |
|
BC100GF |
100 |
6CT |
MP-H-100-4 |
MFKC200A |
|
BC115GF |
115 |
6CT |
MP-H-115-H-4 |
MFKC200A |
|
BC125GF |
125 |
6CTA |
MP-H-120-4 |
MFKC200A |
|
BC140GF |
140 |
6CTA |
MP-H-140-4 |
MFKC200A |
Description:
1. Power Range: 30-140kw
2. Engine: Cummins
3. Alternator: Genuine Stamford, Marathon, Meccalte, etc
4. Controller: Deepsea or Smartgen with or without AMF. Digital display of parameters of diesel engine, and integration of measuring and monitoring.
Options: Remote monitoring of running parameters.
5. Color: Can be customized
Applications:
Marine generators are for boats, ships, and Islands, seashore constructions.
Competitive Advantage:
1. Full power.
2. All genuine engines and alternators.
3. The components we use are in high quality.
4. Use high standard of sponge to make soundproof.
5. Pre and after sales service is provided.
6. Fast response for the inquires, service, etc.
7. With CCS certificate or BV certificate.
Details of Marine diesel generators
