88kva Perkins Diesel Generator Soundproof Stamford Alternator Auto Start ATS

1 SET
MOQ
Negotiation
Price
88kva Perkins Diesel Generator Soundproof Stamford Alternator Auto Start ATS
Features Gallery Product Description Request A Quote
Features
Specifications
Output Power: 80KVA / 64KW
Frequency: 50/60HZ
Voltage: 220/380V 230/400V
Engine: Original UK Perkins 1104A-44TG2
Alternator: Original Stamford Alternator
Controller: Deepsea 6020
MCCB: ABB Or Delixi , 3 Pole
Cooling System: Water Cooled Radiator
Genset Type: Super Silent Soundproof
ATS: ABB / Socommec / Asikai
Warranty Time: 1 Year Or 1000 Hours
High Light:

open type genset

,

water cooled generator

Basic Infomation
Place of Origin: WUXI city CHINA
Brand Name: GPRO
Certification: ISO,CE Certification
Model Number: GP88PS
Payment & Shipping Terms
Packaging Details: Poly wooden case
Delivery Time: 25 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Set / Month
Product Description

88kva Perkins Diesel Generator Soundproof Stamford Alternator Auto Start ATS



1. SPECIFICATIONS OF GEN-SET
1.1 Set Model GP88PS
1.2 Prime at 50HZ, 40℃ ambient 64KW 80KVA
1.3 Standby at 50HZ, 40℃ ambient 70KW 88KVA
1.4 Rated Gen-set output 230/400V 50Hz
1.5 Rated Relative humidity ≤ 60 %
1.6 Dimension (L×W×H) 2600x1000x1485 mm
1.7 Weight 1450kg
1.8 Fuel consumption 100% prime load 215g/kw.h
1.9 Noise Level at 7 (Normal/Super) 75dB
1.10 Structure of Gen-set The Gen-set adopt integrative structure, engine is fix on high strength steel basic frame, anti vibration instrument between the engine and basic frame, cooling fan have protecting cap, control cabinet and circuit breaker installed on Gen-set
1.11 Control system (Optional) Basic control panel or Advanced control panel with automatically start-up function and other function
2. SPECIFICATIONS OF ENGINE
2.1 Engine Brand Original UK Perkins
2.2 Engine Model 1104A-44TG2
2.3 Governor/Class Mechanical Governor
2.4 Cylinder NO. 4
2.5 Engine build Vertical in-line
2.6 Fuel spray pattern direct injection
2.7 Aspiration Turbocharged, air-to-air charge cooled
2.8 Cooling mode Radiator cooled (enclose water)
2.9 Bore and stroke 105×127mm
2.10 Compression ratio 18·3 : 1
2.11 Displacement 4.41L
2.12 Engine Prime Power at 1500rpm 72KWm
2.13 Engine Standby Power at 1500rpm 79KWm
2.14 Start-up mode 12V, electric
2.15 Battery capacity /
2.16 Starting/Min temperature /
2.17 Lubricating oil consumption Lubricating oil consumption less than 10% Fuel consumption
2.18 Lubrication oil capacity 8 litres
2.19 Coolant capacity – radiator and engine (40℃) 12.6litres
2.20 Exhaust temp – full load prime 514°C
2.21 Exhaust gas flow – full load prime 15,2m³/min
2.22 Exhaust gas back pressure max 15 kPa
2.23 Air flow – radiator (40℃ ambient) /
2.24 Pusher fan head (duct allowance) 40℃ /
2.25 Air intake – engine– full load prime 6,01m³/min
2.26 Standard Air intake temp 25℃
2.27 Fuel type #0 Diesel (Natural temperature)
2.28 Filter system Adopt whole changeable lubricating oil, fuel filter and air filter
2.29 Exhaust system Adopt industrial high efficiency silencer and flexible bellows
3. SPECIFICATIONS OF ALTENATOR
3.1 Alternator Model Original Stamford / UCI224G
3.2 Alternator Type A.C. Synchronous
3.3 Rated Voltage 230/400V
3.4 Rated Frequency 50HZ
3.5 Rated speed 1500 RPM
3.6 Voltage regulation mode Auto
3.7 Alternator voltage regulation ±0.5%
3.8 Exciting mode Brushless self exciting
3.9 Power factor 0.8 (lagging)
3.10 Phase & wires 3 phase 12 wires
3.11 Rated currency 144.3A
3.12 Efficiency 0.903
3.13 Insulation class H
3.14 Protection class IP23
3.15 Single load step to NFPA110 100%
3.16 Standards IEC34-1
3.17 Max. Ambient Temperature 40℃
3.18 Min. Ambient Temperature - 20℃
3.19 Max. altitude 1000m
3.20 Weight 415Kg



88kva Perkins Diesel Generator Soundproof Stamford Alternator Auto Start ATS 0

There are many international brand generator controller for our cusomer 's choice,such as Smartgen, Deep sea, Compny, Harson and so on.



ATS: Upon detection of a mains(utility) failure the module automatically starts the generator set, once the mails (utility) power has been restored it instructs the generator set to stop.



Standard Supply Scope:
Generator set included: Diesel Engine, Brushless Alternator, Radiator, self-starting control panel, circuit breaker panel, Vibration damping pads, Hi-strength base frame
Accessories Included: industrial type silencer, flexible bellow, Elbow and Flanges, Starting Battery & battery charger, Battery switch with cables
Documents included: manual book, product qualified card



Optional supply scope:
1.ATS

2.SynchronizationSystem

3.External daily fuel tank

4.Silent Canopy

5.Trailer

6.Auto Fuel Pump

7.Fuel and Water Separator

8.Lub Oil Heater

9.Coolant Heater

10.Fuel Drain Pump



Advantages:

. We are a powerful and unity sales team:

. we are not just sales, but also professional engineers here to give you fast response of Technical support and power solutions.

90% of our sales team members are with more than 5 years of experience in the generator field.

. We have professional electrical & mechanical engineers, standby you, to solve the pre/after-sales service.

. We have strict Inspection dept. to make sure each genset is carefully test before leaving factory.

. With the experience and knowledge of Gensets, we are enthusiastic and patient, and can communicate with you easily and efficiently.



Sales Promises:
. Our company provides a full line of brand new and high quality products which are strictly tested before shipment
. Quality warranty is according to our standard conditions: One year or 1000 running hours



If have any questions, please contact us. Your inquiry would be appreciated.
