FAWDE Engine Electric Low Speed Small Silent Diesel Generator 55kw 230/400 Voltage

FAWDE Engine Electric Low Speed Small Silent Diesel Generator 55kw 230/400 Voltage

  • High Light

    power generating set

    ,

    silent diesel generators

  • Power Rate
    55KW
  • Frequency
    50HZ/60HZ
  • Engine Brand
    FAWDE
  • Voltage
    230/400
  • Alternator
    Chinese Local Brand
  • Warranty
    1 Year Or 1000 Hours
  • Protection Class
    IP23
  • Cooling System
    Water Cooling
  • Type
    Silent
  • Construction Type
    SAE Disc-coupling
  • Place of Origin
    WUXI
  • Brand Name
    GPRO
  • Certification
    ISO9001/ISO14001/CE/PVOC
  • Model Number
    GP69FWS
  • Minimum Order Quantity
    1 set
  • Price
    TBD
  • Packaging Details
    poly wooden case
  • Delivery Time
    30 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    50 sets / Month

FAWDE Engine Electric Low Speed Small Silent Diesel Generator 55kw 230/400 Voltage



FAWDE Engine Electric Low Speed Small Silent Diesel Generator 55kw 230/400 Voltage



Product Description



1. Engine low fuel consumption.

2. All orignal engines and alternators.

3. The components we use are in high quality.

4. Fast delivery. Big quantity of Engines in stock.

5. The generator set is mounted on a heavy duty fabricated steel skid type base frame with anti vibration mounting pads.

6. Use high standard of sponge to make soundproof.

7. The canopy design is user friendly, and easy for maintenance.

8. Pre and after sales service is provided.

9. Fast response for the inquires, service, etc.



Specification of PowerFriend Genset
Genset Genset Model GP69FWS
Prime at 50HZ, 40℃ ambient 50KW 63KVA
Standby at 50HZ, 40℃ ambient 55KW 69KVA
Rated Gen-set output 230/400V 50Hz
Dimension (L×W×H)mm Open: 2100*900*1250
Silent: 2800*1100*1450
Weight Open: 1200kg, Silent: 1700kg
Fuel consumption 100% prime load 15L/H
Rated currency 90A
Circuit Breaker Delixi/CHINT or Customized
Base fuel tank At least for 8-hour contunuous running
Controller Deepsea/ ComAp/ Smartgen
Noise Level/dBA @7m(Silent type only) 65

Engine Engine Brand FAWDE
Engine Model 4DX23-78D
Governor/Class Turbo Electronic
Cylinder NO. & Build 4
Cooling mode Water cooling
Bore and stroke 102×118 mm
Compression ratio 17:01
Displacement 3.86L
Engine Prime Power at 1500rpm 57KWm
Engine Standby Power at 1500rpm 63KWm

Alternator Alternator Brand Stamford type, brushless, 100% copper
Insulation class H
Protection class IP23
