Super Silent Power By Raywin Engine 30kva Three Phase Quiet Generator Set

1 set
MOQ
Negotiation
Price
Super Silent Power By Raywin Engine 30kva Three Phase Quiet Generator Set
Features Gallery Product Description Request A Quote
Features
Specifications
Power(Prime/Standby): 30KVA/ 24KW
Frequency: 50HZ / 60HZ
Current: 50A
Voltage: 220/380V 230/400V
Engine: RAYWIN ENGINE
Controller: Smartgen / DeepSea/ Compa
MCCB: Delixi /ABB
Sound Level/db: 63dB 7 Meter
Warranty: 1 Year Or 1000 Hours
Alternator: Original Stamford
High Light:

power generating set

,

silent diesel generators

Basic Infomation
Place of Origin: WUXI
Brand Name: GPRO
Certification: ISO9001/ISO14001/CE/PVOC
Model Number: GP33RWS
Payment & Shipping Terms
Packaging Details: poly wooden case
Delivery Time: 25 days
Supply Ability: 500 sets / Month
Product Description

Super Silent Power By Raywin Engine 30kva Three Phase Quiet Generator Set



30KVA silent generator specification:

Model 4D24G
Type Vertical In-Line , Water cooled Four stroke
Combustion System DI
Cylinder No. 4
Bore x Stroke 87mm x 103mm
Displacement 2.45L
Compression Ratio 19:01
Induction System Naturally Aspirated
Firing Order 1-3-4-2
Flywheel 7.5 inch
Flywheel Housing SAE 4


Startability & Operating Temperatures:

Aided starting : -30 ℃
Ambient operating temperatures: -30℃ -- 45℃


Easy Service Features:


Same side maintenance
Oil change interval : 250 hrs (500 hrs optional)
Oil / Fuel filter change interval: 250 hrs (500 hrs optional)
Air filter change interval: 250 hrs (500 hrs optional)
Alternator belt replacement : 800 hrs
Valve lash inspect / adjust : 800 hrs
Coolant change: 2 years
Oil consumption : <= 0.1


Physical Characteristics:


Gradeability - all round (Continuous 10 mins ) : 30 30
Gradeability- all round (intermittent - 1 min) : 35 35



Super Silent Power By Raywin Engine 30kva Three Phase Quiet Generator Set 0

Description:


1. Chinese famous brand --RAYWIN ngine

2. Alternator: Italy Mecc alte / Stamford

3. Controller: Deepsea or Smartgen with or without AMF.

4. Options: remote controller, synchronizing.

5. ATS cabinet

6. Type: Silent type, weather proof, Trailer type

Applications:

1.Industrial area: real estate, hospital, hotel, bank, construction, factory, oil field, airport, mining
2. Home use: personal use for house, camping, party, etc
3. Telecom, Mobile tower, etc
4. Island, Desert or any place without electricity
5. As for emergency equipment special for natural disasters, such as typhoon, earthquake

Competitive Advantage:



1. User friendly with low emissions

2. More power reserve, better performance

3. Fast delivery. Big quantity of Engines in stock.

4. Good parts commonality

5. Original RAYWIN engine , good quality , good price.



Company Details:

Wuxi Gpro Power Solution Co., Ltd is focusing on power generator products and service in China.Being in the power generation field for more than 10 years, we have very good connection with G-Drive Engines and brand alternators. We are not only assembling the generator set, but alsogiving you the best solution to meet your special needs on projects and your clients.



Our advantages:
1.Inspection
1) Each engine shall be tested at manufacturer’s workshop to certify the engine output according to present standard and fuel consumption in accordance with the site operating condition specified by purchaser on the specification datasheet.
2) All relevant information drawings pertinent to the testing and test procedure shall be transmitted to the purchaser in advance of the test date notification.
3) All accompanied documents are corresponding to the actual situation of generators, including the Qualified Certificate, Parameters and the Performance Index.

2.Guarantee:
1) Guarantee Period: One year or 1000 running hours, depends on whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.


If you are interested, please contact with us at any time!



Super Silent Power By Raywin Engine 30kva Three Phase Quiet Generator Set 1

Super Silent Power By Raywin Engine 30kva Three Phase Quiet Generator Set 2
