Denyo generator set 15kva super silent 64dB ultra silent genset

1
MOQ
2450
Price
Denyo generator set 15kva super silent 64dB ultra silent genset
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Power: 15KVA/12KW
Standby Power: 17KVA/ 13KW
Noise: 64dB 7 Meters Ultra Silent Type
Fuel Tank: 8 Hours /24 Hours/ 72 Hours
Certificate: ISO9001/ISO14001/CE
Altenrator: Stamford / Mecc / Chinese Brand
Controller: DEEPSEA / SMARTGEN/ HARSEEN
High Light:

emergency diesel generator

,

silent diesel generator set

Basic Infomation
Place of Origin: CHINA
Brand Name: GPRO
Certification: ISO9001/ISO14001 /CE
Model Number: GP17FWS
Payment & Shipping Terms
Packaging Details: poly wooden case / poly bag
Delivery Time: 25 days after get the deposit
Payment Terms: Western Union, T/T, L/C
Supply Ability: 1 set / 25 days
Product Description

Denyo generator set 15kva super silent 64dB ultra silent genset



1. SPECIFICATIONS OF GEN-SET
1.1 Set Model GP17FWS
1.2 Prime at 50HZ, 40℃ ambient 12KW     15KVA
1.3 Standby at 50HZ, 40℃ ambient 13.2KW  17KVA
1.4 Rated Gen-set output 230/400V 50Hz
1.5 Rated Relative humidity ≤ 60 %
1.6 Dimension (L×W×H) Open: 1500*700*1050,
Silent: 2000*940*1200
1.7 Weight Open: 700kg, Silent: 1100kg
1.8 Fuel consumption 100% prime load 4
1.9 Structure of Gen-set The Gen-set adopt integrative structure, engine is fix on high strength steel basic frame, anti vibration instrument between the engine and basic frame, cooling fan have protecting cap, control cabinet and circuit breaker installed on Gen-set.
2 Control system (Optional) Basic control panel or Advanced control panel with automatically start-up function and other function.
2. SPECIFICATIONS OF ENGINE
2.1 Engine Brand FAWDE
2.2 Engine Model 4DW81-23D
2.3 Governor/Class Machanical or Electronic
2.4 Cylinder NO. 4
2.5 Engine build Line
2.6 Emission compliant Stage II
2.7 start-up method 12V, electric
2.8 Air intake type Natural
2.9 Cooling mode Water Cooling
2.10 Bore and stroke 85×100 mm
2.11 Compression ratio 17:01
2.12 Displacement 2.27
2.13 Engine Prime Power at 1500rpm 17KWm
2.14 Engine Standby Power at 1500rpm 19KWm
2.15 Lubrication oil capacity 7.8L
2.16 Oil consumption 0.05
2.17 Dry weight of base 220Kg
2.18 Dry weight of Gen Pac 240Kg
2.19 Overall dimension(G.P) 920×610×760(mm)
2.2 Overall dimension(base) 750×555×680(mm)
2.21 27℃ air consumption ( m³/ min) 1.4
2.22 Fuel type #0 Diesel (Natural temperature)
2.23 Filter system Adopt whole changeable lubricating oil, fuel filter and air filter
2.24 Exhaust system Adopt industrial high efficiency muffler and ripple pipe
3. SPECIFICATIONS OF ALTENATOR
3.1 Alternator Model Stamford/PI 044G
3.2 Alternator Type A.C. Synchronous
3.3 Rated Voltage 230/400V
3.4 Rated Frequency 50HZ
3.5 Rated speed 1500 RPM
3.6 Voltage regulation mode Auto
3.7 Alternator voltage regulation ±0.5%
3.8 Exciting mode Brushless self exciting
3.9 Power factor 0.8 (lagging)
3.10 Phase & wires 3 phase 12 wires
3.11 Rated currency 23A
3.12 Efficiency 81.70%
3.13 Insulation class H
3.14 Protection class IP23
3.15 Single load step to NFPA110 100%
3.16 Standards IEC34-1,NEMA1
3.17 Max. Ambient Temperature 40℃
3.18 Min. Ambient Temperature - 20℃
3.19 Max. altitude 1000m
3.20 Weight 99kg



Description:



1. Chinese FAWDE Diesel Engine

2. Alternator: Stamford / Mecc Alte / Chinese brand engine

3. Controller: UK Deepsea / Smartgen / ComAp / Harseen

4. Options: remote controller, synchronizing.

5. ATS is optional

6. Type: Denyo type ultra silent , 64dB at 7 meters

      7. Color: Any color

      8. Support OEM



Applications:



1. Industrial area: real estate, hospital, hotel, bank, construction, factory, oil field, airport, mining

2. Home use: personal use for house, camping, party, etc

3. Telecom, Mobile tower, etc

4. Island, Desert or any place without electricity

5. As for emergency equipment special for natural disasters, such as typhoon, earthquake, heavy snow





Competitive Advantage:



1. Competitive price

2. Good quality engine and alternator

3. Fast delivery. engine in stock

4. The generator set is mounted on a heavy duty fabricated steel skid type base– frame with anti vibration mounting pads.

5. Use high standard of sponge to make soundproof.

6. The canopy design is user friendly, and easy for maintenance.

7. Pre and after sales service is provided.

8. 365 days, 24 hours after sale service
