CUMMINS / FPT Silent Diesel Generator Set

1 set
CUMMINS / FPT Silent Diesel Generator Set
Features Gallery Product Description Request A Quote
Alternator: Copy Stamford
Controller: Smartgen 6110
Phase: 3 Phase
Warranty: 12 Months/ 1 Year
Cooling System: Water-cooled System
Options: ATS
Type: Silent Type
Colour: Customized
High Light:

emergency diesel generator


silent diesel generator set

Basic Infomation
Place of Origin: China
Brand Name: GPRO
Certification: CE/SONCAP/SASO
Model Number: GP330CCS
Payment & Shipping Terms
Packaging Details: Plywood case
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 300 sets per month
Product Description
Set Model GP330CCS
Prime at 50HZ, 40℃ ambient 240KW 300KVA
Standby at 50HZ, 40℃ ambient 264KW 330KVA
Rated Gen-set output 230/400V 50Hz
Rated Relative humidity ≤ 60 %
Dimension (L×W×H) 3900×1400×2150mm
Weight 3900kg
Fuel consumption 100% prime load 64.7L/h
Total heat radiated to ambient 70KW
Noise Level at 7m (Normal/Super) 80dB
Structure of Gen-set

The Gen-set adopt integrative structure,

engine is fix on high strength steel basic frame,

anti vibration instrument between the engine

and basic frame, cooling fan have protecting cap,

control cabinet and circuit breaker installed

on Gen-set.

Control system (Optional)

Basic control panel or Advanced control

panel with automatically start-up function

and other function.

Engine Brand CUMMINS
Engine Model NTA855G1B
Governor/Class Electrical
Cylinder NO. 6
Engine build Line
Fuel spray pattern PT direct injection
start-up method 24V, electric
Aspiration Turbocharged/Aftercooled
Cooling mode Radiator cooled (enclose water)
Bore and stroke 140×152 mm
Compression ratio 14.0:1
Displacement 14L
Engine Prime Power at 1500rpm 313KWm
Engine Standby Power at 1500rpm 343KWm
Battery capacity 127A/hr
Starting/Min temperature 7℃
Lubrication oil capacity 38.6L
Coolant capacity - radiator and engine (40℃) 70L
Exhaust temp - full load prime 512℃
Exhaust gas flow - full load prime 3723m3/h
Exhaust gas back pressure max 76mmHg
Air flow - radiator (40℃ ambient) 7.2 m 3/s
Pusher fan head (duct allowance) 40℃ 13mmH 2O
Air intake - engine- full load prime 1428m3/h
Standard Air intake temp 25℃
Fuel type #0 Diesel (Natural temperature)
Filter system

Adopt whole changeable lubricating

oil, fuel filter and air filter

Exhaust system

Adopt industrial high efficiency muffler

and ripple pipe

Alternator Model HCI444ES
Alternator Type A.C. Synchronous
Rated Voltage 230/400V
Rated Frequency 50HZ
Rated speed 1500 RPM
Voltage regulation mode Auto
Alternator voltage regulation ±0.5%
Exciting mode Brushless self exciting
Power factor 0.8 (lagging)
Phase & wires 3 phase 12 wires
Rated currency 505.2A
Efficiency 0.935
Insulation class H
Protection class IP23
Single load step to NFPA110 100%
Standards IEC34-1
Max. Ambient Temperature 40℃
Min. Ambient Temperature - 20℃
Max. altitude 1000m
Weight 995.5kg


CUMMINS / FPT Silent Diesel Generator Set 0


CUMMINS / FPT Silent Diesel Generator Set 1




Company Information


Wuxi Gpro Power Solution Co., Ltd is focus on power generator products and service in China.


Being in  the power generation field for more than 10 years, we have very good connection with G-Drive Engines and brand alternators. We are not only assembling the generator set, but alsogiving you the best solution to meet your special needs on projects and your clients. We supply Generator Sets from 2kva to 3000kva.






CUMMINS / FPT Silent Diesel Generator Set 2




Q1: What is your warranty period?

A1: Our warranty period is 1 year or 1000 running hous, whichever comes first(Excep the damageable spare parts of genset caused by incorrect man-made operation).


Q2: Does your generator have global warranty?

A2: Yes. Global warranty service is available depending on the engines and alternators you choose. Please contact us for more details.


Q3: What is your payment terms?

A3: T/T 30% advance payment, the balance 70% shall be paid before shipment.

L/C Irrevocable L/C at sight.


Q4: What is your delivery time?

A4: Our standard delivery time is 20 to 30 days. If you have urgent demand, the delivery will be shorter depending on the requirements. If you have special requirements, the delivery will be longer.


Q5: Can the generators be customized?

A5: Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, inudstrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.


Q6: Can you use our logo?

A6: Yes. For mass orders, we can use customer's logo instead of ours.
