Low Noise Cummins Engine 625kva 500kw Diesel Generator Silent Diesel Gensets
Technical specification | |
Genset Model | GP688CCS |
Prime Power | 500KW/625KVA |
Standby Power | 550KW/688KVA |
Phase Number | 3 |
Power Factor | 0.8 |
Rated Voltage | 230/400V |
Frequency | 50 HZ |
Rated Current | 902A |
Genset Structure | SILENT |
Dimension | 5000×1800×2450mm |
Net Weight | 5500KG |
Noise level | 83dB at 7 meters |
Fuel Tank Capacity | 800L |
Engine Model | KTAA19-G6A |
Engine Features | 6-cylinder,4 stroke,water cooled ,Turbo |
Bore * Stroke | 159mm × 159mm |
Displacement | 18.9L |
MAX Power(kw) | 575KW/1500 |
Fuel Consumption L/H | 129.5L/H |
Compression Ratio | 13:01 |
Governor type | ELECTIC |
Alternator Model | STAMFORD /HCI544FS |
Excitation Mode | brushless self-excited |
Insulation Class | H |
Protection Class | IP23 |
Construction Type | SAE Disc-coupling |
Controler panel | |
Smartgen 6120 | intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.automatic switching control functions (AMF), especially suitable for the automation system composed by Mains and Generator |
