500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder

1 set
MOQ
Negotiation
Price
500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder
Features Gallery Product Description Request A Quote
Features
Specifications
Genset Model: GP688CCS
Frequency: 50 HZ
Prime Power: 500KW/625KVA
Standby Power: 550KW/688KVA
Engine Model: KTAA19-G6A
Engine Features: 6-cylinder,4 Stroke,Turbo
Alternator Brand: STAMFORD /HCI544FS
Cooling Method: Water Cooling
Warranty: 1 Year Or 1000 Hours
Certificates: CE,ISO9001
High Light:

power generating set

,

silent diesel generators

Basic Infomation
Place of Origin: China(Mainland)
Brand Name: GPRO
Certification: ISO9001/ISO14001
Model Number: GP688CCS
Payment & Shipping Terms
Packaging Details: poly wooden case or plastic poly
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: 500 sets / Month
Product Description

500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder



Product describition

Genset Model GP688CCS
Prime Power 500KW/625KVA
Standby Power 550KW/688KVA
Phase Number 3
Power Factor 0.8
Rated Voltage 230/400V
Frequency 50 HZ
Rated Current 902A
Genset Structure SILENT
Dimension 5000×1800×2450mm
Net Weight 5500KG
Noise level 83dB at 7 meters
Fuel Tank Capacity 800L
Engine Model KTAA19-G6A
Engine Features 6-cylinder,4 stroke,water cooled ,Turbo
Bore * Stroke 159mm × 159mm
Displacement 18.9L
MAX Power(kw) 575KW/1500
Fuel Consumption L/H 129.5L/H
Compression Ratio 13:01
Governor type ELECTIC
Alternator Model STAMFORD /HCI544FS
Excitation Mode brushless self-excited
Insulation Class H
Protection Class IP23
Construction Type SAE Disc-coupling
Controler panel
Smartgen 6120 intelligent and network techniques is used for automatic control system of diesel generator. It can carry out functions including automatic start/stop, data measure and alarming.automatic switching control functions (AMF), especially suitable for the automation system composed by Mains and Generator





500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder 0

500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder 1



Description:

Diesel engine is an internal -combustion engine, in which air is compressed to a sufficiently high temperature to ignite diesel fuel injected into the combustion chamber. It can be used to power diesel generator , water pump, tiller etc. Since the future emission standard demands, we are always improving the fuel and engine structures to reduce the impact on environment. "Green Engine" is our target. We always pay more attention to climate protection and environmental.



Package & Payment & Delivery Date & WarrantyPackage:Plastic Package.



Payment: by 30 % T / T as deposit, 70% balance should be paid 10 days before shipment. Or 100 %L/C at sight.

Delivery: 25 days after we get the down payment.

Warranty: All Topower goods are warranted in accordance with our warranty terms for a period of12 months from date of despatch or 1000 running hours from date of commissioning whicheverdate occurs the sooner.





Transation Process:
1. Buyer place order after confirming the details.
2. Seller issue the Proforma Invoice.
3. Buyer pay the advance payment base on the bank details on PI.
4. Seller arrange production immediately after receiving the advance payment.
5. Seller send photos of the products and videos of testing to Buyer.
6. Buyer pay the balance payment after checking the photos and videos.
5. Seller arrange the shipment base on Fob/CNF/CIF/DDU, and send photos of packing and shipping.



FAQ

Q1: What is your warranty period?

A1: Our warranty period is 1 year or 1000 running hous, whichever comes first(Excep the damageable spare parts of genset caused by incorrect man-made operation).

Q2: Does your generator have global warranty?

A2: Yes. Global warranty service is available depending on the engines and alternators you choose. Please contact us for more details

Q3: What is your payment terms?

A3: T/T 30% advance payment, the balance 70% shall be paid before shipment.

L/C Irrevocable L/C at sight.

Q4: What is your delivery time?

A4: Our standard delivery time is 20 to 30 days. If you have urgent demand, the delivery will be shorter depending on the requirements. If you have special requirements, the delivery will be longer.

Q5: Can the generators be customized?

A5: Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, inudstrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.

Q6: Can you use our logo?

6: Yes. For mass orders, we can use customer's logo instead of ours.



500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder 2

500KW 625KVA Cummins Silent Generator Set 4 Stroke 6 Cylinder 3
