24kw 30kva Water Cooled Emergency Diesel Generator 1500 rpm / 1800 rpm Speed

24kw 30kva Water Cooled Emergency Diesel Generator 1500 rpm / 1800 rpm Speed

  • High Light

    emergency diesel generator

    ,

    silent diesel generator set

  • Cooling System
    Water Cooled
  • Fuel Tank
    8 Hours Running
  • Speed Govern
    Electronic
  • Speed
    1500rpm/1800rpm
  • Conditions Of Use
    Land Use
  • ATS
    Optional
  • Place of Origin
    China, Wuxi
  • Brand Name
    GPRO
  • Certification
    CE, ISO
  • Model Number
    GP33YDS
  • Minimum Order Quantity
    1 sets
  • Price
    negotiation
  • Packaging Details
    ply wooden case, plastic
  • Delivery Time
    30 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    400 sets

24kw 30kva Water Cooled Emergency Diesel Generator 1500 rpm / 1800 rpm Speed


Yangdong diesel engine 24kw 30kva new generator set stable power gen​erating


ModelGP33YDS
Rated output(KW)24kw/30kva
Max.output(KVA)26kw/33kva
Frequency(HZ)50
Rated voltage(V)230/400
Rated current(A)54.1
Engine ModelY4100D
Cylinder number6
bore*stroke(mm)100*115
Fuel consumption(g/kw.h)at full load230
Compression ratio19:01
Starting systemElectric starter
Rated Rotation Speed(rpm)1500
Power factor Cos%0.8
Insulation gradeH
Excitation modeself-excitation and cinstant voltage(AVR)
Diamension(L*W*H)2190*1050*1340
net weight(KG)1000


Generator soundproof/silent and canopy
1) Excellent ventilation
2) Black finish stainless steel locks and hinges
3) Zinc plated or stainless steel fasteners
4) Body made from steel components treated with polyester powder coating
5) Two large doors on either side
6) Radiator fill access plate
7) Fully guarded cooling fan and battery charging alternator
8) Fuel fill and battery access via lockable access doors
9) Emergency stop button on canopy exterior
10) Lube oil drain and radiator drain to exterior
11) Control panel viewing window
12) Lifting points on base frame

Testing Items of GPRO Genset:
1) Parts fault testing
2) Fue tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insultion testing
6) Noise testing
7) Loading testing: All qualified generator sets are subjected to a comprehensive performance test which inclides 0% load, 25% load, 50% load, 75% load, 100% load and 110% load and to check, verify that all control systems, alarm and shut-own protection.


Guarantee:
1) Guarantee Period: One year or 1000 running hours, depends on whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.
